HBI-DPS-0401
Industrial 10/100M Edge PoE Switch (4-Port PoE + 1 Uplink)
Reliable Power and Network Connectivity for Smart Building Devices
The HBI-DPS-0401 is an industrial-grade unmanaged PoE Ethernet switch featuring 4 PoE ports and 1 uplink port. Designed for smart building and industrial IoT environments, it supports IEEE 802.3af/at PoE standards, delivering up to 30W per port to power devices such as IP cameras, intercom stations, and access control systems. With rugged industrial design, redundant power input, and extended temperature support, it ensures stable and reliable network infrastructure.
Product Overview
The HBI-DPS-0401 Industrial PoE Edge Switch provides both network connectivity and power delivery for IP devices in smart building and security systems. It includes 4 PoE-enabled Fast Ethernet ports for powering connected devices and 1 uplink port for connection to the core network.
The switch supports IEEE 802.3af/at PoE standards, delivering up to 30W per port with a total PoE power budget of 120W. It also features DIP-switch configuration that enables functions such as VLAN port isolation, long-distance transmission up to 250 meters, QoS prioritization, and PoE watchdog monitoring.
Built for harsh environments, the switch includes IP40 fanless metal housing, DIN-rail installation, surge and ESD protection, and wide temperature operation (-20°C to 75°C). These features make the HBI-DPS-0401 ideal for smart building networks, security systems, and industrial automation deployments.
Key Features
Integrated PoE Power and Networking
4 × 10/100Mbps PoE ports
1 × 10/100Mbps uplink port
Supports IEEE 802.3af/at PoE standards
Up to 30W PoE output per port
Total PoE power budget: 120W
Long Distance Transmission
250m extended transmission mode (Port 1–4)
Ideal for connecting devices located far from the switch
Intelligent DIP-Switch Configuration
VLAN port isolation
QoS priority for ports 1–2
Long-distance mode
PoE watchdog for automatic port recovery
Industrial Reliability
Dual redundant power input (44–57VDC)
Reverse polarity protection
Over-voltage protection
Robust Protection
4KV surge protection
ESD protection (Air 15KV / Contact 8KV)
Rugged Industrial Design
IP40 fanless metal enclosure
DIN-rail installation
Wide operating temperature -20°C to 75°C
HBI-DPS-0401
Industrial 10/100M Edge PoE Switch (4-Port PoE + 1 Uplink)
System Integration
The HBI-DPS-0401 serves as a power and network distribution switch for IP-based building systems.
It connects and powers multiple devices, including:
SIP/IP intercom stations
IP surveillance cameras
Access control readers
Alarm sensors
Smart IoT devices
Building automation controllers
By providing both power and data through Ethernet, the switch simplifies installation and reduces cabling requirements in smart building deployments.
Applications
Smart Building Security
Power and connect IP cameras, video intercoms, and security sensors.
Residential Communities
Support networking for intercom systems, access control, and smart home devices.
Industrial Automation
Provide reliable Ethernet and PoE connectivity for factory monitoring systems and industrial IoT devices.
Transportation Infrastructure
Deploy PoE networking for station surveillance and monitoring equipment.
Education & Campus Networks
Enable PoE connectivity for security cameras and building automation systems across campus environments.
Product Specifications
Model | HBI-DPS-0401 | Power Consumption | ≤4W (without PoE) |
Ethernet Ports | 4 × 10/100M PoE + 1 × 10/100M uplink | Connector | Removable 4-pin terminal block |
PoE Standard | IEEE 802.3af / IEEE 802.3at | Surge Protection | 4KV |
Max PoE Power | 30W per port | ESD Protection | Air 15KV / Contact 8KV |
PoE Power Budget | 120W | Protection Rating | IP40 |
Switching Capacity | 1Gbps | Installation | DIN-Rail |
Packet Forwarding Rate | 1.48Mpps | Operating Temperature | -20°C ~ 75°C |
MAC Address Table | 2K | Storage Temperature | -40°C ~ 85°C |
VLAN | 4K | Humidity | 5–95% non-condensing |
Jumbo Frame | 2K Bytes | Dimensions | 30 × 98 × 130 mm |
Forwarding Delay | <10µs | Weight | 0.5 kg |
Power Input | 44–57VDC redundant power inputs | Certification | CCC / CE / FCC / RoHS |
Max Input Current | 3A | Warranty | 2 Years |
Compatible Products:
The HBI-DPS-0401 works with various HomeScenario smart building devices, including:
SIP/IP Video Intercom Stations
Indoor Touch Panels
Multi Access Control Systems
IP Surveillance Cameras
Alarm and Security Sensors
IoT Controllers and Automation Devices
Smart Building Management Systems
FAQs:
Q: What devices can be powered by the HBI-DPS-0401?
A: The switch can power PoE devices such as IP cameras, SIP intercom stations, access control readers, and IoT devices that support IEEE 802.3af or 802.3at standards.
Q: What is the maximum PoE power per port?
A: Each PoE port supports up to 30W of power output (PoE+).
Q: What is the total PoE power budget?
A: The switch provides a maximum total PoE power budget of 120W for connected devices.
Q: What is the purpose of the PoE watchdog feature?
A: The PoE watchdog automatically restarts ports when connected devices stop responding, improving system reliability.
Q: Can the switch support long-distance connections?
A: Yes. With long-distance mode enabled, the switch supports up to 250 meters transmission for ports 1–4.
Q: Is the switch suitable for industrial environments?
A: Yes. The switch supports -20°C to 75°C operating temperature, surge protection, and a rugged IP40 metal enclosure designed for industrial use.
